Unique Flush-Mount Design

Integration of Horizontal AND Vertical Components
Allows Multi-point Affixing of Panels on the Same Plane

Smart. Simple. Limitless.

Where Clever Engineering Meets Maximum Design Flexibility.

One Complete System for All Cladding Materials

Terracotta, Stone, Brick, Ceramic, Fiber Cement, ACM, Composite, Zinc, +

EXTERIOR

CL-TALON 300

- Tech/Spec/CAD- CEUs- LEED

CL-TALON® 300

Integrated Smart-TrackTM System

Why Choose CL-TALON for Rainscreen & ci Applications

The CL-TALON 300 is a cleverly engineered “Smart-Track” support system that offers design flexibility and truly integrates the structural elements, supporting all exterior cladding materials with one single product selection for rainscreen and ci wall applications.

CL-TALON 300

Thermally-isolated, high-performance system for exterior use.

Clear Aluminum Finish

Black Anodized Finish

Product Details

1. Base Track
2. Therme Clip
3. Wall Mount T-Track
4. Wall Mount Support
5. Finish Perimeter for Windows/Doors, etc.
6. Space for Continuous Insulation
7. Waterproof Membrane
8. Integrated Measurements

Components

Finishing Accessories

  • Termination solutions
  • Seamless finished corners, windows & doors

One Complete System that Does it All

High Thermal Performance

Third-party tested – 91% thermal efficiency. Efficient thermal break achieved with polyamide clips. LEED Design Credits: Energy & Atmosphere + Materials & Resources, +

Integrates with all Cladding Materials

Terracotta, Stone, Brick, Ceramic, Fiber Cement, ACM, Composite, Zinc, +

Universal Installation

Horizontal AND/OR Vertical.

Optional Horizontal Flush-mounts

Horizontal and vertical attachment layers imbed as an integrated solution for multi-point affixing of panels on the same plane. Minimizes extension of the cladding from the substrate.

Increased Stability Behind Panels

Helps prevent oil canning deformation over time, specifically for thinner panel formats.

Accuracy to Design

Integrated install measurements, leveling and minute adjusting capability.

Finishing Accessories

Address termination points for corners, windows & doors. Corners can be properly supported - including a wide range of acute and obtuse angles.

Insulation Accommodation

Accommodates 2”- 8” of insulation.

Aluminum & Polyamide Components

Lightweight and strong extruded aluminum Base-Track, T-Track, Horizontal Flush-Mount*Polyamide Clip – clip strength + thermal break

Customization

Custom track lengths and system depths available.

Track Colors

Black Anodized or Silver Aluminum.

Global Responsibility

High Thermal Performance

Third-party tested – 91% thermal efficiency.

  • Third-party tested – reached 91% thermal efficiency.
  • Efficient thermal break achieved with polyamide clips.

LEED Building Design

The CL-TALON cladding support system is an environmentally responsible product that provides high-performance thermal isolation required for effective continuous insulation design.

LEED Credits

Energy & Atmosphere

  • Exceeds ANSI/ASHRAE/IESNA Standard 90.1–2010 by eliminating any conductive fastener penetration of the insulation.

Materials & Resources

  • Aluminum elements have 30.5% post-consumer recycled content and may be valued at 85% of the cost of those elements in calculating the credit.

View the LEED Brochure for specific details.

Leadership in Energy & Environmental Design

DOWNLOAD PDF

Up to the Challenge

Rigorously Tested to Meet Challenging Conditions

All CL-TALON products are made with 100% aluminum alloy which is less corrosive than powder coated or heavier steel alternatives and can therefore extend the life of the façade, especially in high moisture or saline rich environments.

Third-party Fire, Water, Air, Structural & Gravity testing includes: NFPA 285, ASTM E331, ASTM E330, ASTM E283.

View our Technical Information for more details.

Technical
Data Sheet

DOWNLOAD PDF

Quick, Safe, Easy to Install.

Why Contractors Love Our Products

  • Pre-marked measurements etched into the face of Base & T-Tracks.
  • No shimming needed at the substrate – less time and damage to the membrane.
  • Plumb vertical leveling and finite depth adjustments are all done on the outside track – fast and easy.
  • Slide-in ThermeTM Clips - saves time versus plumbing and leveling individual clips over a large space.
  • Optional pre-installed clip in location on the Base Track.
  • Slide-in-track leveling device included.
  • Base-Track attachment to the substrate provides slide-in rails – helps hold components together if the building or materials shift.
  • Aluminum material composition makes the system both strong and lightweight.
